Edwards Cryo-Torr Cryopump 8200 Helium Compressor, 1 phase, Water Cooled, 208/230 VAC.
Edwards Part Number: 8032550G002.

For applications, process, maintenance engineers, and scientists who depend on Cryogenic Compressors in fields such as vacuum coating, semiconductor production, particle accelerators, sputter deposition systems and Molecular Beam Epitaxy. The Edwards 8200 compressor is designed to provide optimum performance with On-Board Cryopumps, On-Board Waterpumps and Cryo-Torr Cryopumps.

This Edwards 8200 Single Phase Water Cooled Compressor is designed for reliable performance with a variety of Cyro-Pumps up to 8 inches in size including the CTI Cryo-Torr series. The Edwards 8200 model compressors can operate on both 50 and 60Hz, easily switchable using the frequency toggle switch, located right on the front. The 8200 can also be toggled between high and low voltage from a frontward located S1 switch; 50hz (180-220VAC), 60Hz (198-250VAC).
A Users and Configuration Manual is provided by downloading the pdf.

Can be used with the the following Cryo-Pumps

On-Board 4, On-Board 8, On-Board 250, Cryo-Torr 8 or Cryo-Torr 250 Cryopump or On-Board Waterpump (350 refrigerator) See configuration manual .pdf below for proper installation.

ON-BOARD-4-6-8-250-400-500-Brooks-Cryopump-Install-Maint-Manual.pdf (ON-BOARD-4-6-8-250-400-500-Brooks-Cryopump-Install-Maint-Manual.pdf, 1,163 Kb) [Download]

Cryo-Pumps_Install_1.pdf (Cryo-Pumps_Install_1.pdf, 941 Kb) [Download]

Brooks_CryoPump_Module_Programming_Operations.pdf (Brooks_CryoPump_Module_Programming_Operations.pdf, 1,301 Kb) [Download]

CTI-Cryo-Blanket-Heaters.pdf (CTI-Cryo-Blanket-Heaters.pdf, 429 Kb) [Download]

Brooks8200-Compressor-MAN_1.pdf (Brooks8200-Compressor-MAN_1.pdf, 995 Kb) [Download]

Cryo-Torr_9600_Compressor_1.pdf (Cryo-Torr_9600_Compressor_1.pdf, 1,750 Kb) [Download]

Cryo-Torr_Analog_Display_Temp_Indicator.pdf (Cryo-Torr_Analog_Display_Temp_Indicator.pdf, 44 Kb) [Download]

8040366_Three-Phase-Motor-Controller-Manual.pdf (8040366_Three-Phase-Motor-Controller-Manual.pdf, 565 Kb) [Download]

CTI-OnBoard-Programming-Op-Manual.pdf (CTI-OnBoard-Programming-Op-Manual.pdf, 1,301 Kb) [Download]

CTI-On-Board-Networking-of-Pumps.pdf (CTI-On-Board-Networking-of-Pumps.pdf, 1,537 Kb) [Download]

CTI-Cryo-torr100-7-8-8F_Manual.pdf (CTI-Cryo-torr100-7-8-8F_Manual.pdf, 1,456 Kb) [Download]

CTI-8500-Compressor.pdf (CTI-8500-Compressor.pdf, 1,185 Kb) [Download]

LakeShoreTempMonitor_.pdf (LakeShoreTempMonitor_.pdf, 280 Kb) [Download]
