| Category | Push-Pull Compact Power, air side plugs |
|---|---|
| Bakeout temperature | 392 °F |
| Max. bakeout temperature | 200 °C |
| Wire termination | Solder |
| Max. wire cross section | 20 |
| Strain relief | Yes |
| Contacts included | Yes |
| Contact coating | Gold-plated |
| Article no. | 101936 |
| Number of contacts | 8 |
| Plug connections | Not specified |
| Material insulation | PEEK |
| Material contact(s) | Copper alloy |
| Magnetic | No |
| Min. operating temperature | -50 °C |
| Min. operating temperature | -58 °F |
| Max. operating temperature | 200 °C |
| Max. operating temperature | 392 °F |
| Outer diameter | 17,5 mm |
| Outer diameter | 0.689 ″ |
| Length | 59 mm |
| Length | 2.323 ″ |
| Length 2 | 44 mm |
| Length 2 | 1.732 ″ |
