| Category | With mini plug |
|---|---|
| Bakeout temperature | 842 °F |
| Max. bakeout temperature | 450 °C |
| Article no. | 301689 |
| Connection type | KF |
| Nominal diameter | 16 |
| Leakrate | < 1E-9 mbar ∙ l/s |
| Number of TC pairs | 5 |
| Impedance | Not specified |
| Shield | Not specified |
| Plug connections | Air side |
| Flange material | Stainless Steel 304L |
| Material housing/weld adapter | Stainless steel 304L |
| Material insulation | Alumina ceramic |
| Thermocouple type | K |
| Magnetic | Yes |
| Min. operating temperature | -269 °C |
| Min. operating temperature | -452.2 °F |
| Max. operating temperature | 450 °C |
| Max. operating temperature | 842 °F |
| Outer diameter | 30 mm |
| Outer diameter | 1.181 ″ |
| Diameter | 1,3 mm |
| Diameter | 0.051 ″ |
| Length | 91 mm |
| Length | 3.583 ″ |
| Length 2 | 78 mm |
| Length 2 | 3.071 ″ |
| Length 3 | 69 mm |
| Length 3 | 2.717 ″ |
| Purity class | PCS |
