CF40-MPCTC5-10-SE-CE-K Type MIL-DTL-5015 Type MIL-DTL-5015
Delivery
Payment options
Our advantages
- — 12 months warranty
- — SMS notification
- — Return and exchange
- — Different payment methods
- — Best price
| Category | Type MIL-DTL-5015 |
|---|---|
| Bakeout temperature | 842 °F |
| Max. bakeout temperature | 450 °C |
| Article no. | 300342 |
| Connection type | CF |
| Nominal diameter | 40 |
| Leakrate | < 1E-9 mbar ∙ l/s |
| Number of TC pairs | 10 |
| Impedance | Not specified |
| Shield | Not specified |
| Plug connections | Air side |
| Flange material | Stainless Steel 304L |
| Material housing/weld adapter | Stainless steel 304L |
| Material insulation | Alumina ceramic |
| Thermocouple type | K |
| Magnetic | Yes |
| Min. operating temperature | -269 °C |
| Min. operating temperature | -452.2 °F |
| Max. operating temperature | 450 °C |
| Max. operating temperature | 842 °F |
| Diameter contact(s) | 1,6 mm |
| Diameter contact(s) | 0.063 ″ |
| Outer diameter | 70 mm |
| Outer diameter | 2.756 ″ |
| Length | 57 mm |
| Length | 2.244 ″ |
| Length 2 | 78 mm |
| Length 2 | 3.071 ″ |
| Length 3 | 13 mm |
| Length 3 | 0.512 ″ |
| Purity class | PCS |
